Name: Tuning Fork Crystal Resonator TF 3.2*1.5
Uploaded: 2026-06-08T10:56:00+08:00

Tuning Fork Crystal Resonator TF 3.2*1.5 TF 3.2*1.5

Item	TF 3.2×1.5
Output Type	Fundmental
Frequency Renge (F0)	32.768KHZ
Frequency Tolerance (at 25°C)	±20ppm ±50ppm
Operating Temperature Range (TOPR)	-40°C ~ +85°C, -40°C ~ +125°C or specify
Storage Temperature Range (TSTG)	-55°C ~ +125°C
Drive Level (DL)	typecial 0.1μw, 1μw Max
Turnover Temprature (Ti)	25°C ± 5°C
Parabolic Coefficient (B)	-0.04×10-6/°C2 Max
Load Capacitance (CL)	7pF, 9pF, 12.5pF or specify
Motional Resistance (ESR)	60KΩ Max, 70KΩ Max
Motional Capacitance (C1)	8.4 fF Typ.
Shunt Capacitance (C0)	1.6 pF Typ.
Frequency Aging (First Year)	3×10-6/year Max.
In addition to the parameters listed in the table, it can be designed according to customer needs

Consult sales representative for other specifications.
