Name: Quartz Crystal Resonator SMD 2.0*1.6
Uploaded: 2026-06-08T16:35:00+08:00

Quartz Crystal Resonator SMD 2.0*1.6 SMD 2.0*1.6

TYPE	SMD2.0×1.6
Frequency range	12MHz ~ 96MHz
Crystal cut and Mode	AT/FUND
Frequency Tolerance (at 25°C)	±5ppm ~ ±20ppm, or specify
Frequency Temperature Characteristics	±10ppm (-20°C - 70°C); ±30ppm (-40°C - 85°C), or specify
Operating Temperature Range	-40°C ~ +125°C
Storage Time.Range	-55°C ~ +125°C
Equivalent Series Resistance (ESR)	See Table
Load Capacitance (CL)	5pf ~ ∞
Shunt Capacitance (Co)	< 3pf
Insulation Resistance	> 500MΩ At DC 200V
Drive Level	10μw ~ 200μw
Aging (Year)	±1ppm (Year), ±3ppm (Year)

Frequencies vs Equivalent Series Resistance

Frequency (MHz)	Mode	ESR (Ω) SMD2.0×1.6
12.000 ≤ f < 20.000	AT/FUND	≤ 100
20.000 ≤ f < 30.000	AT/FUND	≤ 60
30.000 ≤ f < 54.000	AT/FUND	≤ 40
In addition to the parameters listed in the table, it can be designed according to customer needs

Consult sales representative for other specifications.
