Thermistor Crystal Resonator TSX 2.5*2.0
TSX 2.5*2.0
Thermistor Crystal Resonator TSX 1.6*1.2 TSX 1.6*1.2
Item | TSX 1.6×1.2 | |
Frequency Renge (F0) | 24 ~ 96 MHZ | |
Frequency Tolerance (at 25°C) | ±3 ~ ±10 ppm, or specify | |
Frequency Stability Over Operating Temperature Range | ±10 ppm, or specify | |
Operating Temperature Range | -30~ 85 °C, -40~ 125 °C or specify | |
Shunt Capacitance (C0) | 3 pF Max. | |
Drive Level (DL) | 1 ~ 100μW (50μW Typical) | |
Load Capacitance (CL) | 7 pF, 8 pF, 10 pF, or specify | |
Storage Temperature Range | -55 ~ +125 °C | |
Thermistor Resistance (25°C) | 100 kΩ, or specify | |
Thermistor B-constant (25~50°C) | 4250, or specify | |
Motional resistance (ESR) | 26~30MHZ | 80Ω Max |
30~96MHZ | 50Ω Max | |
Aging (at 25°C) | ±1 ppm / year; ±3 ppm / year Max. | |
In addition to the parameters listed in the table, it can be designed according to customer needs | ||
Consult sales representative for other specifications.
