Name: Thermistor Crystal Resonator TSX 2.5*2.0
Uploaded: 2026-06-05T17:44:00+08:00

Thermistor Crystal Resonator TSX 2.5*2.0 TSX 2.5*2.0

Item		TSX 2.5×2.0
Frequency Renge (F0)		12 ~ 54MHZ
Frequency Tolerance (at 25°C)		±3 ~ ±10ppm, or specify
Frequency Stability Over Operating Temperature Range		±10ppm, or specify
Operating Temperature Range		-30~ 85 °C, -40~ 125 °C or specify
Shunt Capacitance (C0)		3 pF Max.
Drive Level (DL)		1 ~ 200μW (100μW Typical)
Load Capacitance (CL)		7 pF, 8 pF, 10 pF, or specify
Storage Temperature Range		-55 ~ +125 °C
Thermistor Resistance (25°C)		100 kΩ, or specify
Thermistor B-constant (25~50°C)		4250, or specify
Motional resistance (ESR)	12 ~ 13MHZ	120Ω Max
	14 ~ 30MHZ	80Ω Max
	30 ~ 54MHZ	50Ω Max
Aging (at 25°C)		±1 ppm / year; ±3 ppm / year Max.
In addition to the parameters listed in the table, it can be designed according to customer needs

Consult sales representative for other specifications.
